Описание товара
Factory Direct sale 2017 Hot Sale High Temperature Vacuum Furnace
Application:
vacuum sintering furnace is applied for powder metallurgy, such as stainless steel sintering (injection and silk screen) and magnetic material, such as aluminumalnico and samarium cobalt.
1. Technical Specifications
|
Vacuum Furnace |
VF-1200T |
VF -1400T |
VF -1700T |
|
Max temperature |
1200C |
1400C |
1700C |
|
Working temperature |
≤1100C |
≤1300C |
≤1600C |
|
Heating rate |
0-20C/min |
||
|
Temperature accuracy |
± 1C |
||
|
Temperature control |
51segments programmable and PID auto control |
||
|
Max. Vacuum |
10Pa ,7x10-2Pa ,7x10-3Pa |
||
|
Furnace chamber |
Ceramic fiber |
||
|
Furnace structure |
Double shell with fan cooling |
||
|
Thermocouple |
K type |
S type |
B type |
|
Heating elements |
Fe-Cr-Al-Mo wire |
Sic heater |
MoSi2 heater |
|
Voltage |
110V/415V 50Hz/60Hz |
||
2. Temperature’s profile for your reference as below.
( for example: 6 segments)
3.Heating elements
|
Working temperature |
Product Pictures |
Heating elements |
Characteristics |
|
W T≤1200C |
|
Fe-Cr-Al-Mo wire |
Compared with the ordinary iron chromium aluminum wire resistance, higher temperature and more durable |
|
W T≤1400C |
|
SiC heater |
Using high temperature, anti-oxidation, corrosion resistance, long life, small deformation, easy installation and maintenance. |
|
W T≤1750C |
|
MoSi2 heater |
Suitable for ultra high temperature heating, long service life, high calorific value and economic price |
4. Trouble shooting for typical Problems
|
Problems |
Reason |
Solution |
|
Open Power Lock, no power indication |
Fuse (4A) in control panel is broken |
Check control panel, and replace fuse |
|
Green Power indictor is off, but Red open circuit indicator is On |
Fuse ( 50A) in main power circuit is broken |
Open the cover of front panel and replace the fuse |
|
No current shows in meter , but has Max. Voltage |
Heating element broken |
Find broken heating rod, and replace it |
|
Controller display panel SV shows“ OraL” |
Thermal Couples broken |
Replace Thermal couples ( B type ) |
|
Controller display panel SV shows“ HI AL” |
Furnace temperature > 1700C, Protection from Alarm |
Cool furnace down, and find reason why temperature is so high ( program setting may be wrong) |
|
Power and heating element are OK, but furnace can’t be controlled by program. |
Controller or related circuit may be damaged |
Heck controller. |
|
Program running, but furnace can not be heated, or real temperature is far behind the setting value |
oPL or oPH value is too low due to local voltage lower or frenquency different |
Incraese “oPL” and “oPH” value till current meter shows “ 120 A – 140 A”, and program runs smoothly |
|
During heating below 300C, the temperature value ( PV) is not stable, and doesn’t match with setting program (SV) |
It is normal because the furnace comes with a high temperature thermocouple, which is not sensitive at temperature below 300C |
Don’t worry. Let the furnace heat to 300C, then thermocouple will function stably with program. If the PV value at 300C is still less than that of SV, you may need to increase OPL value a little. |
|
|
|
5.Payment Terms:
We accept Payment L/C, T T
Price terms : FOB china
6.Transporation
By sea ,we have good forwarders ,super service and price ! Especially ,it is free to ship by sea sometimes!
7.Other services:
Our productions can be able to customize . You can send an Email to us with the dimensions of the parts and the name of polymer attached to the parts. Our engineers will develop the most appropriate top quality high temperature laboratory furnace for you! :)
8.Main Products:
1, Muffle furnaces / Box furnaces / Chamber furnaces / Lab fu
3,Atmosphere furnaces / Vacuum Furnaces
4,Silicon Carbide Heating Elements
5,Molybdenum Disilicide Heating Elements
6,Other Furnaces related products
FAQ:
Are you a manufacturer?
Yes, we have been manufacturing different models of furnaces for years.
What quality standard you have acquired?
All our products are CE approval.
Do you have your own R&D team?
Yes, we have R&D department, a group of retired personnels and highly educated expertise staff.
They will make the products perfect and design your requirements for free.
What temperature you can make?
Usually the Max.temperature include 3 levels: 1200C/ 1400C/ 1700C
The heating elements we are using are:
|
Max. Temperature |
Heating Elements |
|
1200C |
Fe-Cr-Al-Mo wire |
|
1400C |
Quality SiC heater |
|
1700C |
MoSi2 heating element |
What information should i let you know if i want to get a quotation?
It’s best for you to offer us the chamber size,temperature,etc.
How many days will the goods be finished?
Usually stocks are available.If stock finish,the standard sizes take one week to finish.
For non-standard sizes,30 working days after receiving the down payment.
Do you inspect the finished products?
Yes,each step of production and finished products will be carried out inspection by QC department before shipping.
How do you ship the products?
By sea;
By plane;
By couriers, DHL, TNT, Fedex, UPS, etc.
